Retrieving and storing data from a HEC-DSS file is done through the class HecDss in the hec.heclib.dss package. The first call that should be made is the static member HecDss.open(string filename), which will return a HecDss object to retrieve and store data, as well as perform math and other functions.

You need to import the classes that you use as well as the hec.script package. To do this, include a subset of the following lines at the beginning of your script:

from hec.script import Plot, MessageBox
from hec.io import TimeSeriesContainer
from hec.io import PairedDataContainer
from hec.hecmath import TimeSeriesMath
from hec.hecmath import PairedDataMath
from hec.heclib.dss import HecDss, DSSPathname, HecDataManager

from hec.heclib.dss import HecDss, DSSPathname


HecDss.open(string filename)
HecDss.open(string filename, string startTime, string endTime)
HecDss.open(string filename, string timeWindow)
HecDss.open(string filename, Boolean fileMustExist)

The HecDss class is used to gain access to an HEC-DSS file, as illustrated below. You must import HecDss from hec.heclib.dss.

from hec.heclib.dss import HecDss

theFile = HecDss.open("MyFile.dss")
#or
theFile = HecDss.open("C:/temp/sample.dss", True)


#Finished using the file – release it
theFile.done()

Using one of the methods that specifies a time window affects the operation of the get() and read() methods as described in the Pattern Strings section below.

Note: The preferred manner of releasing access to an HEC-DSS file in most cases is to use the done() method and not the close() method. This is because HEC-DSS maintains information about file access and can grant access to a file released with done() much more quickly than it can to one released with close(). HEC-DSS will close files when a script exits or when they have not been accessed for a while. The only time that the close() method should be called explicitly is to perform some operating system operation on it, such as renaming or deleting the file.

HecDss Retrieve and Store Functions

HecDss objects are used to retrieve and store data sets in a DSS file, as well as several utility functions for DSS files. Data is retrieved and stored using DataContainers. DataContainers are simple classes that are database independent and are how most Hec classes exchange data. DataContainers are a base class for several data types, such as time series data, paired data, gridded data, etc. DataContainers and their related classes are described following the HecDss class. If the data set you are retrieving does not exist, the DataContainer will have the numberValues set to 0 (zero).

HecDss, and most classes accessed through scripts, use Java Exceptions for error handling. Use a try block to catch and process errors. If data cannot be stored, HecDss will throw an exception. Refer to Handling Exceptions in Scripting Basics for more information.

Tip: From the HEC-DSSVue main screen, select a pathname, right click and select Copy Pathnames to Clipboard. You can then paste the pathname into your script and avoid having to type it. You cannot use condensed pathnames for these functions.

The HecDss methods for retrieval, storage, and utility methods are described in the tables below.  Time Series Data Storage Constants (Regular and Irregular) are also shown below.

HecDss Retrieval and Storage Methods

HecDss Additional Primary Methods

from javax.swing import JOptionPane
from hec.heclib.dss import HecDss
from hec.script import Plot
import java

try :
  try :
    myDss = HecDss.open("C:/temp/sample.dss")
    flow = myDss.get("/RUSSIAN/NR UKIAH/FLOW/01MAR2006/1HOUR//")
    plot = Plot.newPlot("Russian River at Ukiah")
    plot.addData(flow)
    plot.showPlot()
    plot.stayOpen()
  except Exception, e :
    JOptionPane.showMessageDialog(None, ' '.join(e.args), "Python Error", JOptionPane.ERROR_MESSAGE)
  except java.lang.Exception, e :
    MessageBox.showError(e.getMessage(), "Java Error")
finally :
  myDss.done()

The following plot is displayed when running the script above.  The plot includes Marcy of 2016 because there is a date '01MAR2016' in the path.

from hec.script import Plot,MessageBox
from hec.heclib.dss import HecDss
import java

try :
  myDss = HecDss.open("C:/temp/sample.dss")
  flow = myDss.get("/MISSISSIPPI/ST. LOUIS/FLOW//1DAY/OBS/", 1)

  if flow.numberValues == 0 :
    MessageBox.showError("No Data", "Error")
  else :
    plot = Plot.newPlot("Mississippi")
    plot.addData(flow)
    plot.showPlot()

except Exception, e :
    MessageBox.showError(' '.join(e.args), "Python Error")
except java.lang.Exception, e :
    MessageBox.showError(e.getMessage(), "Error")
finally :
  myDss.done()

Example 17 results in a plot of the entire data set because the D part (date) of the path was left blank.

from hec.script import Plot, MessageBox
from hec.heclib.dss import HecDss, HecTimeSeries
from hec.io import TimeSeriesContainer
from hec.heclib.util import HecTime
import java

try:
    myDss = HecDss.open("myFile.dss")
    tsc = TimeSeriesContainer()
    tsc.fullName = "/Basin/loc/FLOW/01NOV2002/1Hour//"
    start = HecTime("01Nov2022","0800")
    tsc.interval = 60
    flows = [0.0,2.0,1.0,4.0,3.0,6.0,5.0,8.0,7.0,9.0]
    times =[]

    for value in flows:
        times.append(start.value())
        start.add(tsc.interval)

    tsc.times = times
    tsc.values = flows
    tsc.numberValues = len(flows)
    tsc.units ="CFS"
    tsc.type = "PER-AVER"
    myDss.put(tsc)

except Exception, e:
    MessageBox.showError(''.join(e.args),"Python Error")

finally:
    myDss.close()

11:57:20.724      -----DSS---zopen   Existing file opened,  File: c:\programs\HEC-DSSVue-v3.2.1.130\myFile.dss
11:57:20.724                         Handle 3;  Process: 2424;  DSS Versions - Software: 7-HV, File:  7-HV
11:57:20.724                         Single-user advisory access mode
11:57:20.725 -----DSS--- zwrite  Handle 3;  Version 2:  /Basin/loc/FLOW/01Nov2022/1Hour//
11:57:20.725      -----DSS---zclose  Handle 3;  Process: 2424;  File: c:\programs\HEC-DSSVue-v3.2.1.130\myFile.dss
11:57:20.726                         Number records:         1
11:57:20.726                         File size:              15826  64-bit words
11:57:20.726                         File size:              123 Kb;  0 Mb
11:57:20.726                         Dead space:             0
11:57:20.726                         Hash range:             8192
11:57:20.726                         Number hash used:       1
11:57:20.726                         Max paths for hash:     1
11:57:20.727                         Corresponding hash:     2734
11:57:20.727                         Number non unique hash: 0
11:57:20.727                         Number bins used:       1
11:57:20.727                         Number overflow bins:   0
11:57:20.727                         Number physical reads:  9
11:57:20.727                         Number physical writes: 8
11:57:20.727                         Number denied locks:    0

HecDss Secondary Methods

¹ Currently, the read(…) and write(…) methods can operate only on time-series data, paired data, stream rating data, and text data  represented by TimeSeriesMath, PairedDataMath, and StreamRatingMath TextMath objects, respectively.  Other record types, such as gridded data are not yet supported by these methods.

² By default, TimeSeriesMath objects retrieved via calls to read(…) contain data only between the first non-missing value and the last non-missing value within the specified time window.  Calling setTrimMissing(False) causes the data retrieved to include all data for the specified time window, including blocks of missing values at the beginning and end of the time window.

Time Series Data Storage Constants (Regular and Irregular)

Pattern Strings

The pattern strings used with the getCatalogedPathnames(…) methods filter the list of returned pathnames in a user-specified manner. Pattern strings can be specified in two modes: pathname mode and pathname part mode. Both modes make use of pathname part filters:

• Pathname mode = /Afilter/Bfilter/Cfilter/Dfilter/Efilter/Ffilter/
• Pathname part mode = [A=Afilter] [B=Bfilter] [C=Cfilter] [D=Dfilter] [E=Afilter] [F=Ffilter]

In pathname mode, filters must be supplied for all pathname parts.  In pathname part mode, only those parts that will not match everything must be specified.

Filters are comprised of the following components:

Normal text characters.  These characters are interpreted as they appear.  For example, a pattern string of "B=XYZ" specifies matching every pathname that has a B-part of "XYZ".

Special characters.  The special characters are comprised of the following list:

• '@' or '*' (used interchangeably).  This character can be specified as the first and/or last character of a filter and specifies matching a string of zero or more characters.  For example, a pattern string of "B=XYZ@" specifies matching every pathname that as a B-part that begins with "XYZ".  A pattern string of "B=*XYZ" specifies matching every pathname that has a B-part that ends with "XYZ".  A pattern string of “B=*XYZ*” specifies matching every pathname that "XYZ" anywhere in the B-part.  Note that the @ or * character must be the first and/or last character of the filter (e.g. a pattern string of "B=ABC*XYZ" is invalid).
• '#' or '!' (used interchangeably).  This character must be specified as the first character of a filter and specifies matching of every string except the remainder of the filter (e.g. it negates the remainder of the filter).  A pattern string of "B=!XYZ*" specifies matching every pathname that does not have a B-part that begins with "XYZ".

• No character. The absence of any character specifies an empty filter, which matches a blank pathname part.  Both of the following pattern strings match every pathname that has a blank A-part

  • "//*/*/*/*/*/"
        ●  "A="

Using getCatalogedPathnames(…) with a pattern string utilizes the pathname matching in the underlying DSS library. To accomplish more sophisticated pathname filtering, use one of the getCatalogedPathnames(…) methods in conjunction with python text parsing and matching utilities.

Time Windows

Dates and times used to specify time windows should not contain blank characters and should include the 4 digit year. An example date and time is "04MAR2003 1400". If a single string is used to specify the time window, the starting date and time must precede the ending date and time, for example dssFile.setTimeWindow ("04MAR2003 1400 06APR2004 0900"). A relative time may be used in the single string command, where the letter "T" represents the current time, and the days or hours can be subtracted or added to that. For example dssFile.setTimeWindow("T-14D T-2H") would specify the starting time as current time minus fourteen days and the ending time as the current time minus two hours.

Time Windows (specified by starting time and ending time) effect how the DSSFile.read(…) method operates for the various data types.
■ Time-series data. The time window supplied to DSS.open(…) or dssFile.setTimeWindow(…) specifies the default time window for all subsequent dssFile.read(…) operations. If no time window is supplied to DSS.open(…) then the default time window is undefined until dssFile.setTimeWindow(…) is called. If the default time window is undefined, then all dssFile.read(…) operations involving time-series data must specify a time window either implicitly via the D-part of the specified pathname or explicitly via the startTime and endTime parameters. The order of precedence for time windows is as follows:
● Explicit time window. Specified in dssFile.read(pathname, startTime, endTime) or dssFile.read(pathname, timeWindow). The D-part of the pathname is ignored and may be empty.
● Default time window. Specified in DSS.open(filename, startTime, endTime) or DSS.open(filename, timeWindow) or dssFile.setTimeWindow(startTime, endTime) or dssFile.setTimeWindow(timeWindow). The D-part of the pathname is ignored and may be empty. The default time window can be set to undefined by calling dssFile.setTimeWindow("", "").
● Implicit time window. Specified as the D-part of the pathname supplied to dssFile.read(pathname) when the default time window is undefined. The D-part of the pathname must not be empty.
■ Paired data. Time windows have no effect on reading paired data records.
■ Stream rating data. Stream rating data are comprised of a time-series of individual rating records for a common location. The reading of stream rating data is not affected by default time windows. The implicit time window for reading stream rating data is the entire time span covered by the rating records. An explicit time window may be supplied by using the dssFile.read(pathname, startTime, endTime) method. If an explicit time window is specified, a (possible) subset of the rating records is retrieved that
cover the specified time window. The explicit time window is interpreted as the time window containing all time-series data that is to be rated via the stream rating data. The set of rating records retrieved for an explicit time window meets the following criteria.
● The earliest record retrieved is the latest rating that is on or before the start of the time window. If no such record exists, the earliest record in the rating time-series is retrieved.
● The latest record retrieved is the earliest rating that is on or after the end of the time window. If no such record exists, the latest record in the rating time-series is retrieved.
● All rating records between the earliest and latest retrieved records are also retrieved.
■ Text data. Time windows have no effect on reading text records.
